Features *8-channel full-duplex optical transceiver module *Hot-pluggable QSFP-DD/OSFP MSA-compliant form factor *Compliant with CMIS, SFF-8636 and SFF-8665 *Data rate up to 850Gbps *Case operating temperature range from 0 to 70℃ *EEPROM customized with I²C interface *RoHS compatible (lead free)
|
P/N |
|
Data Rate |
Reach |
Connector |
Tx |
|
800G-OSFP-SR8 |
OSFP LPO |
800GbE |
50M |
MMF/MPO-16 |
850nm |
|
800G--OSFP-DR8 |
OSFP LPO |
800GbE |
500M |
SMF/MPO-16 |
1310nm |
|
800G--OSFP-2*DR4 |
OSFP LPO |
4*400G 400G |
500M |
SMF/Dual MPO-12 |
1310nm |
|
800G-OSFP-2*SR4 |
OSFP DSP |
800GbE |
100M |
MMF/Dual MPO-12 |
850nm |
|
800G-OSFP-DR8 |
OSFP DSP |
800GbE |
500M |
SMF/Dual MPO-12 |
1310nm |
|
800G--OSFP-2*FR4 |
OSFP DSP |
2*400Gbps |
10KM |
SMF/Dual Duplex LC |
2*CWDM4 |
|
800G-QSFP-DD-SR8 |
QSFP-DD DSP |
800GbE |
100M |
SMF/MPO-16 |
850nm |
|
800G-QSFP-DD-DR8 |
QSFP-DD DSP |
800GbE |
500M |
SMF/MPO-16 |
1310nm |
|
800G-QSFP-DD-2*FR4 |
QSFP-DD DSP |
800GbE |
2KM |
SMF/Dual CS |
2*CWDM4 |
