Developed based on the Intel Xeon 6 SP platform, this server supports up to 2 Intel Xeon BHS-SP processors. Equipped with 32 DDR5 memory slots and 28 drive bays, it delivers excellent expandability. Featuring a power efficiency of up to 96% and a standard operating temperature range of 0°C to 40°C, it achieves superior energy efficiency. It is ideal for diverse scenarios including virtualization, high-performance computing and big data applications.
| Model | R5220 V7 |
| Processor | Support up to 2 × Intel® Xeon® 6 scalable processors, with up to 144 cores and a power of up to 330 W for each processor |
| Memory | Support up to 32 × DDR5 memory slots, with a speed of up to 6400 MT/s, supporting RDIMM |
| Support 16 memory expansion slots using CXL | |
| Storage controller | Support the high-performance RAID controller, and RAID0/1/10/5/6/50/60 |
| Storage extension | Support up to 28 × hard disks |
| Support up to 20 × 3.5-inch hard disks (12 in front, 4 internally installed and 4 in rear) | |
| Support up to 25× 2.5-inch hard disks, (25 in front ) | |
| Support up to 38 × NVMe U.2 hard disks (24 in front, 4 in rear) | |
| Support SATA/NVMe M.2 options | |
| Network extension | 1 × Gbps onboard private management network port |
| Support 2 × OCP 3.0 network cards | |
| Support the network adapter based on standard PCIe slot | |
| PCIe extension | Support up to 9 × PCIe expansion slots |
| Support up to 7 × standard PCIe expansion slots | |
| Support 2 × OCP 3.0 onboard slots | |
| Management software | Integrate with BMC management chip AST2600, support IPMI2.0, Redfish, SOL, KVM, virtual media and other functions |
| GPU support | Support up to 4 × dual-width GPU cards with a power consumption of up to 600 W for single card |
| I/O | Provide standard configuration of 1 × management network port, 1 × rear VGA port and 5 × USB ports (2 in front, 1 internally installed and 2 in rear) |
| Optional intelligent lug: 1 front VGA port, 1 front management network port or support for 1 front Type-C private management port (used for BMC/system serial port), and 1 rear Type-C private management port (used for BMC/system serial port) | |
| Security | Support chassis intrusion detection; support Intel PFR3.0 and SGX2.0 security technologies; support TCM/TPM security module |
| Power | Support 800 W / 1300 W /1600 W /2000 W /2600 W / 2700 / 3200 W CRPS standard power supply, with 1+1 redundancy |
| Operating temperature | 5℃～45℃ (operating temperature is affected by different configurations, please refer to the product technical document for details) |
| Form Factor / Chassis Dimensions |
2U 87mm(H)*447.4mm(W)*800mm(D) (excluding security bezel) |
